Measurements

• Dimensions: 35 x 32 x 8.5 cm
• Weight: 3kg

Fetal Heart Rate

• Working frequency: 1.0MHz
• Strength: <5 mW/cm²
• Transducer: Multi-crystals, wide wave beam, pulsed-wave working mode
• Signal processing: special digital signal
• Measurement range: 50-210 bpm / 30-240 bpm
• Alarm Range:
  • High limit: 160, 170, 180, 190 bpm
  • Lower limit: 90, 100, 110, 120 bpm
  • Maximum audio output: 1.5 W

TOCO

• Measurement range: 0-100 units

Maternal SpO2 measurement

• Measurement scope: 70%-99%
• Measurement accuracy: ±3%

HR Measurement

• Measurement scope: 30 bpm – 240 bpm
• Measurement accuracy: ±2 bpm

NIBP Measurement

• Systolic pressure measuring range: 6.7 – 32.0kPa (50 – 240mmHg)
• Mean pressure measuring range: 3.4 – 26.6kPa (25 – 200mmHg)
• Diastolic pressure measuring range: 2.0 – 24.0kPa (15 – 180mmHg)
• Accuracy: ±1kPa (±8mmHg) or reading ±5%, whichever has the greater absolute value
• Pulse rate measuring range: 40 bpm – 240 bpm
• Pulse rate accuracy: ±2 bpm or reading ±5%, whichever has the greater absolute value
• Measurement mode: manual / automatic NIBP measurement

Body Temperature

• Range: 0 – 50°C
• Resolution: 0.1°C
• Accuracy: ±0.1°C (excluding sensor error)

Display

• Resolution: 800 x 600

Power

• Power supply: AC 100-240V, 50/60Hz
• Power Consumption: ≤80VA
• Battery: 14.8V Li-ion battery

Operating Environment

• Temperature: +5°C ~ +40°C
• Humidity: 30% – 70%
• Atmospheric pressure: 86kPa – 106kPa

Transport and Storage

• Temperature: -10°C ~ +55°C
• Humidity: <93%
• Atmospheric pressure: 86kPa – 106kPa
