Features
- 30 parameters including 4 research parameters, 3 scattergrams and 3 histograms
- Tri-angular laser scatter + Flow cytometry for 5-partWBC counting
- Independent BASO counting channel
- 4 TFT Colored LCD with Touch Screen
- Throughput: 60 samples per hour
- Sample Type: Whole Blood, Peripheral Blood, Pre-diluted Blood
- Built-in Thermal printer
Technical Specifications
- Parameters: WBC, BAS#, BSA%, NEU#, EOS#, EOS%, LYM#, LYM%, MON#, MON%, RBC, HGB, HCT, MCV, MCH, MCHC,RDW-CV, RDW-SD, PLT, MPV, PDW, PCT, P-LCR, P-LCC; ALY#, ALY%, LIC#, LIC%;WBC Histogram, RBC Histogram, PLT Histogram;2D DIFF Scatter gram x3; 3D DIFF Scatter gram x1;
- Testing Mode: CBC, CBC+DIFF
- Principle: Electrical impedance, Colorimetry; Laser scattering method
- Sample Volume: Prediluted: 20uL (CBC + DIFF/CBC); Whole blood: 15uL (CBC + DIFF/CBC)
- Throughput: 60 samples per hour
- Display: 10.4″ TFT color LCD with touch screen
- Alarms: Error messages
- Input/Output: RS-232, USB, LAN, keyboard and mouse interface
- Printout: Thermal printer, 55mm width paper, varous
- Operating Environment: Temperature: 15-25℃
- Power Requirement: AC 110V-220V, 50/60Hz
- Dimension: L×W×H（mm): 470*365*525
- Weight: 31Kg
