Features
- 28 Parameters
- 2 Histograms, 2 Scattergrams
- 60 samples/hour
- Autoloader for 50 sample tubes
- 3-D Topographic Maps for WBC
- Integral Titanium Incubation System
- Laser Scatter Technology
- Constant Linear Sheath Flow
- Random Direction Tube Barcode Scanning Technology (Optional)
Technical Specifications
Technology:
- 3-D Topographic Map
- Integral Titanium Incubation System
- Laser Scatter Technology
- Flow Cytometry Technology
- Cyanide Free Reagents
- Random Direction Tube Barcode Scanning Technology
Parameters:
- Regular Parameters: WBC, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD,RDW-CV, PLT, PDW, MPV, PCT, P-LCR, NEU#,NEU%,LYM# ,LYM%,MON# ,MON% EOS# EOS%, BAS#, BAS%
- Research Parameters: AL Y#, ALY%, IG#, IG%
- 2 Histograms, 2 Scattergrams
Test Speed:
- Autoloader Mode: 60 Samples/hour
- Close Tube Mode: 60 Samples/hour
- Histograms, 2 Scattergrams
Test Mode:
- CBC+5DIFF, CBC
Sampling Mode:
- Autoloader: 50 tubes position random direction tube barcode scanning technology
- Close Tube: STAT priority, support both whole blood and capillary blood samples
Performance:
- WBC 0-99.9×109/L ≤1.0% ≤2.0%
- RBC 3-7.0×1012/L ≤1.0% ≤1.5%
- HGB 20-240g/l ≤1.0% ≤1.5%
- PLT 20-999×109/L ≤1.0% ≤4.0%
QC & Calibration:
- Multiple QC rules, including L-J, X-B etc
- Automated and manual calibration function for both whole blood mode and pre-diluted blood mode
Power Supply:
- 100V-240V, 50Hz/60Hz
Operation Environment:
- Temperature: 15℃-30℃
- Humidity: 30%-85%
- Weight: 75KG
- Dimension: 61cm (L) ×76cm (W) ×61cm (H)
